SPECIFICATIONS

Brand Name: NONE

High-concerned chemical: None

Origin: US(Origin)

General

• Type: Electric Off-Road U-T-V (4-W-D)

• Seating Capacity: 2 persons

• Condition: New

• Certification: CE, COC (road/export compliance)

• Warranty: 1 year

Dimensions & Weight

• Length × Width × Height:
  2960 × 1640 × 1980 mm

• Vehicle Weight: ~840 kg

• Ground Clearance: 255 mm

• Turning Radius: 4.8 m

Powertrain & Performance

• Motor: 5 kW AC asynchronous motor

• Drive System: 4WD (four-wheel drive)

• Battery: 48V / 170Ah (Lithium or Lead-acid optional)

• Speed: 30–50 km/h adjustable

• Range: 70–90 km (flat road conditions)

• Charging Time: 6–8 hours

• Climbing Ability: ~10–20% grade

Braking & Safety

• Brakes: Front & rear hydraulic disc brakes

• Parking Brake: Electronic parking brake (optional)

• Braking Distance: <6 meters

Suspension & Handling

• Front Suspension: Independent double swing arm + coil spring + hydraulic shock

• Rear Suspension: Integral axle + coil spring + hydraulic shock + stabilizer

• Steering: Rack-and-pinion (optional EPS power steering)

Load & Utility

• Payload Capacity: ~200 kg

• Cargo/Storage: Built-in compartments for tools & equipment

Electrical & Features

• Charger: 48V intelligent onboard charger

• Charging Efficiency: <8 hours for ~80% charge

• Lighting: LED lighting system

• Cab: Fully enclosed (agricultural/off-road use)

• Windshield: Foldable front windshield

📌 General Information / Key Features

• Designed for agriculture, farms, ranches, and off-road utility work

• Fully enclosed cab for weather protection and safety

• Electric drivetrain → quiet, low maintenance, eco-friendly

• Strong torque for hills and rough terrain

• Suitable for:

  • Farms & forestry

  • Resorts & large properties

  • Industrial sites

  • Off-road transport

⚙️ Summary (Quick View)

• Power: 5 kW electric motor

• Range: up to 70–90 km

• Top Speed: up to 50 km/h

• Drive: 4WD

• Seats: 2

• Weight: ~840 kg

• Use: Agricultural / off-road utility
